MiniRobotLanguage (MRL)
STR.Extract
Extract Substring Up to a Specified Character or String
Intention
This Command is used to extract a substring from a main string, starting from an optional position and up to the first occurrence of a specified string.
This is particularly useful for parsing strings containing arguments or delimited strings.
�The Command is case-sensitive.
�If P3 is zero, or beyond the length of P1, a null string is returned.
�If P3 is negative, the starting position is counted from right to left.
�If P2 is not present in P1, or either string parameter is null, all of P1 is returned.
Syntax
STR.Extract|P1|P2|P3[|P4]
STR.Ext|P1|P2|P3[|P4]
Parameter Explanation
�P1 - Source string from which to extract.
�P2 - String to search for.
�P3 - Optional starting position in the source string.
�P4 - Optional variable for result (if omitted, result is placed in P1).
Example
'***********************************
' STR.-Sample
'***********************************
$$SRC=<Hello, World!>
$$SEA=World
$$STA=1
STR.Extract|$$SRC|$$SEA|$$STA|$$RES
' $$RES will contain "Hello, "
ENR.
Remarks
-
Limitations:
-
See also:
? � �
�
See also:
? STR.StrBetween - Extract between delimiters
? STR.GrabBetween - Advanced extraction
? STR.ExtractAny - Extract until any char
