! Sample Script: Picture to 3D Logo





Sample Image-Processing Script:



P3   -> clip0150 clip0151





' Turning a b/w picture into a 3D-Logo




$$BOR=4

CAL.$$BOB=$$BOR/2



IEF.$$PAB

  ANA.Load|1|$$PAB

  'ANA.Show|1!

ELS.

  MBX.File does not exist:$crlf$$$PAT

EIF.



ANA.GetRes|1|$$XPO|$$YPO

CAL.$$XPA=$$XPO+$$BOR

CAL.$$YPA=$$YPO+$$BOR



' Make a Resized Version of P3

ANA.New|2|$$XPA|$$YPA|1

ANA.New|3|$$XPA|$$YPA



' Now mix Shiftzed and Resized Version

ANA.bsh|2|1|$$BOB|$$BOB|1

ANA.Invert|1

'ANA.bw|1|100

ANA.bw|2|600

ANA.Show|1!

ANA.Show|2!

ANA.Logic|3|1|2|A XOR B|RGB

ANA.Show|3!

'ANA.MixTar|1|2|2

ANA.Invert|3

ANA.Show|3!

ENR.



' Changing the first two lines like this, will produce the second picture:

$$BOR=2

CAL.$$BOB=$$BOR
