MiniRobotLanguage (MRL)
Keycode-List
Key Code List
Intention
These Keycodes are available with KYD., KYU., SKP. and other Compatible Engine Keyboard-Typing Commands.
This is the most compatible and "Low Level" Keyboard simulation we have. Using these commands, you can even make window to bring up the Task-Manager, by simulating a Key-press:
' Bring Windows Task-Manager up
KYD.{STRG},{SHIFT},{ESC}
PAU.0.100
KYU.{STRG},{SHIFT},{ESC}
ENR.
' This example will open a Menu in Photoimpact
' using the SHFT-CTRL-S Key-Combination
'
STW.ct|IE3_CLASS|PhotoImpact -
SCW.nc|1|Afx:400000:0:10013:0:0
KYD.{SHIFT},{CTRL}
SKP.s
KYU.{SHIFT},{CTRL}
PAU.0.2
RET.
You can read more about Keyboard-Simulation and Text-Boxes in the chapter:
Keycode-List
Low-Level-Keycodes:
Special- Keycode Simulates:
Sequence
{LMB} - 1 - Left MouseButton
{RMB} - 2 - Right MouseButton
{CANCEL} - 3 - Click on CANCEL (see 30)
{MMB} - 4 - Middle Mouse Button
{MSX1} - 5 - Mouse-X1 Key
{MSX2} - 6 - Mouse-X2 Key
{BS},{BACKSPACE} - 8 - BACKSPACE (deletes to left side)
{TAB} - 9 - TAB
{DEL},{CLEAR} - 12 - Delete-Key (deletes to right side),
see also 46
{RETURN} - 13 - RETURN-Key
{SHIFT} - 16 - SHIFT-Key (general), for L/R
see 160,161
{CTRL},{STRG} - 17 - CTRL-Key (general), for L/R
see 162,163
{ALT},{MENU} - 18 - ALT-/MENU-Key (general), for L/R
see 164 and 165
{PAUSE} - 19 - PAUSE-Key
{CAPSLOCK} - 20 - CAPS-LOCK - Key
{KANA} - 21 - KANA-Key,HANGUL-Key
{JUNJA} - 23 - JUNJA-Key,
{FINAL} - 24 - FINAL-Key
{KANJI} - 25 - KANJI-Key, HANJA-Key
{ESC} - 27 - ESCAPE-Key
{CONVERT} - 28 - CONVERT-Key
{NOCONVERT} - 29 - NOCONVERT-Key
{ACCEPT} - 30 - ACCEPT-Button (see 3)
{MODECHANGE} - 31 - MODECHANGE-Key
{SPACE} - 32 - SPACE-key
{PAGEUP},{PGUP] - 33 - PAGE-UP Key
{PAGEDOWN},{PGDN} - 34 - PAGE-DOWN
{END} - 35 - END-Key
{POS1},{HOME} - 36 - HOME/POS1-Key
{LEFT} - 37 - Left Arrow-Key
{UP} - 38 - Up Arrow-Key
{RIGHT} - 39 - Right Arrow-Key
{DOWN} - 40 - Down Arrow-Key
{SELECT} - 41
{PRINT} - 41
{EXECUTE} - 43
{SNAPSHOT},{SNAP} - 44 - Print Screen-Key
{INSERT} - 45 - INSERT-Key
{DELETE} - 46 - DELETE-Key
{HELP} - 47
- - 48-57 Numbers 0-9
{KP_01} - 48 - Keypad-Modifier, together with
SHIFT (160) will be
Specialcharacter "*" on the Keypad
{KP_02} - 56 - Keypad-Modifier, together with
SHIFT (160) will be
Specialcharacter "(" on the Keypad
{KP_03} - 57 - Keypad-Modifier, together with
SHIFT (160) will be
Specialcharacter ")" on the Keypad
- - 65-90 Alphabet letter a-z
{LWIN} - 91 - Left Windows-Button
{RWIN} - 92 - Right Windows Button
{APPS} - 93 - APPS-Key, often left to the right
CTRL-Key. Opens Menus.
{SLEEP} - 95
{NUM_0} - 96 - Numerical Key-Pad Number 0
{NUM_1} - 97 - Numerical Key-Pad Number 1
{NUM_2} - 98 - Numerical Key-Pad Number 2
{NUM_3} - 99 - Numerical Key-Pad Number 3
{NUM_4} - 100 - Numerical Key-Pad Number 4
{NUM_5} - 101 - Numerical Key-Pad Number 5
{NUM_6} - 102 - Numerical Key-Pad Number 6
{NUM_7} - 103 - Numerical Key-Pad Number 7
{NUM_8} - 104 - Numerical Key-Pad Number 8
{NUM_9} - 105 - Numerical Key-Pad Number 9
{NUM_MUL} - 106 - Numerical Key-Pad Multiplication
{NUM_ADD} - 107 - Numerical Key-Pad Addition
{NUM_SEP} - 108 - Numerical Key-Pad Separator Key
{NUM_SUB} - 109 - Numerical Key-Pad Subtraction
{NUM_DOT} - 110 - Numerical Key-Pad Decimal Point
{NUM_DIV} - 111 - Numerical Key-Pad Divide Key
{F1} - 112 - Function Key F1
{F2} - 113 - Function Key F2
{F3} - 114 - Function Key F3
{F4} - 115 - Function Key F4
{F5} - 116 - Function Key F5
{F6} - 117 - Function Key F6
{F7} - 118 - Function Key F7
{F8} - 119 - Function Key F8
{F9} - 120 - Function Key F9
{F10} - 121 - Function Key F10
{F11} - 122 - Function Key F11
{F12} - 123 - Function Key F12
{F13} - 124 - Function Key F13
{F14} - 125 - Function Key F14
{F15} - 126 - Function Key F15
{F16} - 127 - Function Key F16
{F17} - 128 - Function Key F17
{F18} - 129 - Function Key F18
{F19} - 130 - Function Key F19
{F20} - 131 - Function Key F20
{F21} - 132 - Function Key F21
{F22} - 133 - Function Key F22
{F23} - 134 - Function Key F23
{F24} - 135 - Function Key F24
{NUM},{NUMLOCK} - 144 - NUMLOCK-Key
{SCROLLOCK} - 145 - SCROLLOCK-Key
{LSHIFT} - 160 - Left SHIFT Key
{RSHIFT} - 161 - Right SHIFT Key
{LCTRL},{LSTRG} - 162 - Left CTRL-Key
{RCTRL},{RSTRG} - 163 - Right CTRL-Key
{LALT},{LMENU} - 164 - Left ALT-Key
{RALT},{RMENU} - 165 - Right ALT-Key, ALT Gr.
Hint: To get ALT Gr, you need to use the
two Keys: 165 and 162. See example below.
{BROWSEBACK},{BBACK} - 166
{BROWSERFWD},{BFWD} - 167
{REFRESH},{BREFRESH} - 168
{BROWSERSTOP},{BSTOP} - 169
{BROWSERSEARCH},{BSEARCH}- 170
{BROWSERFAVS},{BFAVS} - 171
{BROWSERHOME},{BHOME} - 172
{MUTE} - 173
{VOLDN},{VOLUMEDOWN} - 174
{VOLAUP},{VOLUMEUP} - 175
{NTRACK},{NEXTTRACK} - 176
{PTRACK},{PREVTRACK} - 177
{MEDIASTOP},{MSTOP} - 178
{MPAUSE},{PLAYPAUSE} - 179
{MAIL},{LAUCHNMAIL} - 180
{MSELECT},{MEDIASELECT} - 181
{LAUCHAPP1} - 182 - Launch Application 1 (may be
Windows-Explorer)
{LAUCHAPP2} - 183 - Launch Application 2 (may be
Windows-Calculator)
{OEM_1},{UE},{UML_UE} - 186- German "Ü"-Umlaut
{OEMPlus} - 187
{OEMComma} "," - 188
{OEMMinus} - 189
{OEMPeriod} - 190
{OEM_2} "#" - 191
{OEM_3},{OE},{UML_OE} - 192 - German "Ö"-Umlaut
{OEM_4} - 193
{OEM_5} - 194
{OEM_6} - 195
{OEM_7} - 196
{SS},{GER_SS} - 219 - German "ß"-Umlaut
{HIGH} "^" - 220
{AE},{UML_AE} - 222- German "Ä"-Umlaut
{PIPE} "|" - 226 - the "<"-Key, below the "a",
only on german keyboards.
{PROCESS} - 229
{ATTN} - 246
{CRSEL} - 247
{EXSEL} - 248
{EREOF} - 249
{PLAY} - 250
{ZOOM} - 251
{PA1} - 253
{OEMCLEAR} - 254
