MiniRobotLanguage (MRL)
SDL.txt2img / SDL.t2i
Use Local Stable Diffusion using the native JSON-Body without using internal Registers.
Intention
The SDL.txt2img command is designed to convert a text prompt into a visual image.
This is particularly useful for generating images based on textual descriptions or prompts.
The command takes a complete JSON-Structure (P1) and a target file path (P2) where the generated image will be saved.
Syntax
SDL.txt2img|P1|P2
Parameter Explanation
•P1 - Parameters: Specifies the parameters for generating the image. This includes the text prompt, styles, seed, subseed, sampler name, batch size, number of iterations, steps, configuration scale, width, height, and whether to restore faces.
•P2 - Target File Path: Specifies the file path where the generated image will be saved. It may contain a "?" which may be replaced by a number, if the file name is not unique.
Example
$$PRO=neural network beautiful golden girl Galaxy robot digital photorealistic NC-1701 enterprise
' Use Image Register 0
$$IMR=0
$$EXT="prompt": "$$PRO",
'$$EXT+"styles": ["string"],
$$EXT+"seed": -1,
$$EXT+"subseed": -1,
$$EXT+"sampler_name": "Euler",
$$EXT+"batch_size": 1,
$$EXT+"n_iter": 3,
$$EXT+"steps": 50,
$$EXT+"cfg_scale": 7,
$$EXT+"width": 512,
$$EXT+"height": 512,
$$EXT+"restore_faces": true,
SDL.t2i|$$EXT|$$FIL
'SDL.Show Error
ANA.Load|$$IMR|$$FIL
$$TXT=SPR/SDO. generated.
$$COA=&HFFFFFF
$$COB==&H0
$$BGC=-2
$$XPA=30
$$YPA=450
ANA.PrintAt|$$IMR|$$TXT|$$COA|$$BGC|$$XPA|$$YPA|24
ANA.PrintAt|$$IMR|$$TXT|$$COB|$$BGC|($$XPA+1)|($$YPA+2)|24
DBP.Loaded in IR:$$IMR -> $$FIL
ANA.Show|$$IMR
ANA.Save|$$IMR|$$FIL
'SDL.gpr|$$RET
DBP.$$RET
ENR.
Remarks
Following you can see the possible Parameters.
{
"enable_hr": false,
"denoising_strength": 0,
"firstphase_width": 0,
"firstphase_height": 0,
"hr_scale": 2,
"hr_upscaler": "string",
"hr_second_pass_steps": 0,
"hr_resize_x": 0,
"hr_resize_y": 0,
"hr_sampler_name": "string",
"hr_prompt": "",
"hr_negative_prompt": "",
"prompt": "",
"styles": [
"string"
],
"seed": -1,
"subseed": -1,
"subseed_strength": 0,
"seed_resize_from_h": -1,
"seed_resize_from_w": -1,
"sampler_name": "string",
"batch_size": 1,
"n_iter": 1,
"steps": 50,
"cfg_scale": 7,
"width": 512,
"height": 512,
"restore_faces": false,
"tiling": false,
"do_not_save_samples": false,
"do_not_save_grid": false,
"negative_prompt": "string",
"eta": 0,
"s_min_uncond": 0,
"s_churn": 0,
"s_tmax": 0,
"s_tmin": 0,
"s_noise": 1,
"override_settings": {},
"override_settings_restore_afterwards": true,
"script_args": [],
"sampler_index": "Euler",
"script_name": "string",
"send_images": true,
"save_images": false,
"alwayson_scripts": {}
}
Limitations:
-
See also:
•
