MiniRobotLanguage (MRL)
SDL.Img2Img Intern
Initiates the Image-to-Image process using the Stable Diffusion API from Automatic1111, generating one or multiple images based on the parameters set.
Intention
The SDL.Img2Img Intern command is designed to start the Image-to-Image process using the Stable Diffusion API.
It takes an original image (P1) and a target path (P2) to generate new images.
The command can produce multiple images depending on the Internal Parameter registers that are set using these commands:
SDL.Set Style Free
SDL.Set Prompt
SDL.Set negative Prompt
SDL.Set Sampler
SDL.Set Steps
SDL.Set Scale
SDL.Set Size
All other parameters must be set using the SDL.Set Extra Parameters command.
An optional parameter (P3) can be used to return the paths of all generated images.
The Image-Parameters need a special processing and are therefore specified directly with the command,
Syntax
SDL.Img2Img Intern|P1|P2[|P3]
Parameter Explanation
•P1 - Original Pic: Specifies the file path of the original image to be processed.
•P2 - Target Path: Specifies the target file path where the new image(s) will be saved. Can contain a "?" to indicate multiple images.
•P3 - (Optional): Variable for Result Path: A variable to store the file paths of all generated images. If omitted, these are placed on the Top Of Stack (TOS).
Returns a list of File names of all generated files, separated using the "*".
Example
'***********************************
' SDL.-Sample
'***********************************
$$PRO=girl,hero,propaganda,sexy,epic,russia
$$NEG=ugly,unnatural, fat
$$EXT=
$$EXT+"denoising_strength": 0.75,
$$EXT+"batch_size": 3,
$$EXT+"n_iter": 1,
$$EXT+"restore_faces": true,
$$EXT+"tiling": false,
SDL.Set Extra Parameter|$$EXT
SDL.Set Prompt|$$PRO
SDL.Set negative Prompt|$$NEG
SDL.Set Scale|7
SDL.Set Size|512|512
SDL.Set Steps|90
SDL.Img2Img Intern|$$IMG|$$TAR|$$RES
MBX.Generated Files: $$RES
ENR.
-->
Remarks
-
Limitations:
-
See also:
•
