This Chapter contains the new Pattern-Recognition Engine Commands.
Get more detailed Information about the usable Pattern-Sizes and the Debug-Flag, here:
Currently "Undocumented Commands":
ANA.FindPattern5|P1|P2|P3|P4|P5|P6|P7|P8|P9|P10|P11
This command will search for 5 different Patterns in one Run. These could be different Sizes of something.
Target IR is always IR 0
First Pattern-IR is always IR 1 alle further Patterns must be in the IR's 2 to 5
P1 + P2 - Color-Tolerance and PixelHits Pattern 1
P3 + P4 - Color-Tolerance and PixelHits Pattern 2
P5 + P6 - Color-Tolerance and PixelHits Pattern 3
P7+ P8 - Color-Tolerance and PixelHits Pattern 4
P9 + P10 - Color-Tolerance and PixelHits Pattern 5
P11 - Debug Flag
