MiniRobotLanguage (MRL)
SDL.Set Extra Parameter
Add extra Parameter to the JSON that is sent to the Local Stable Diffusion server
Generated using SDL. and "n_iter:2" as extra Parameter.
Intention
The JSON used with SDL. is very different then what is sent to the Cloud Server using SDO.
Also the technical details are not available Online, but only
when the local Server is running, via the URL: http://127.0.0.1:7860/docs#/default/text2imgapi_sdapi_v1_txt2img_post
Anyway you can add Extra-Parameter, these will be saved in an internal Register (there is one for SDL. and another for SDO.)
this will insert the content of this register without any change into the JSON before its sent to the Server.
If the Variable is empty it will not be inserted.
There is not Syntax checking, the given Parameter will be inserted as it is.
If the resulting JSON is invalid, the call will not produce a picture and instead will result in an error-message.
Due to the refined Scripting language of the SPR, handling JSON is very easy. You can just copy the Line from the JSON below, enter your value and thats it.
If you want to add multiple Extra Parameters separate them with a , (Comma).
SDL.Set Extra Parameter|"save_images": true,"n_iter": 2
SDL.Set Extra Parameter|"restore faces": true
' Technically you could also change the Model like this:
$$MOD=v2-1_768-nonema-pruned.ckpt
SDL.Set Extra Parameter|"override_settings": {"sd_model_checkpoint": "$$MOD"}
This the complete List of parameters that can be used for the Local Server.
In the following list, those parameters that are already included in the
SDL.Generate Picture to File/Var Command, are written in bold letters. Please do not use them a second time, just include them using the Standard Registers.
In case you include Text that needs to be escaped, its up to you to do so using the AIC.Escape - Command.
{
"enable_hr": false,
"denoising_strength": 0,
"firstphase_width": 0,
"firstphase_height": 0,
"hr_scale": 2,
"hr_upscaler": "string",
"hr_second_pass_steps": 0,
"hr_resize_x": 0,
"hr_resize_y": 0,
"hr_sampler_name": "string",
"hr_prompt": "",
"hr_negative_prompt": "",
"prompt": "",
"styles": [
"string"
],
"seed": -1,
"subseed": -1,
"subseed_strength": 0,
"seed_resize_from_h": -1,
"seed_resize_from_w": -1,
"sampler_name": "string",
"batch_size": 1,
"n_iter": 1,
"steps": 50,
"cfg_scale": 7,
"width": 512,
"height": 512,
"restore_faces": false,
"tiling": false,
"do_not_save_samples": false,
"do_not_save_grid": false,
"negative_prompt": "string",
"eta": 0,
"s_min_uncond": 0,
"s_churn": 0,
"s_tmax": 0,
"s_tmin": 0,
"s_noise": 1,
"override_settings": {},
"override_settings_restore_afterwards": true,
"script_args": [],
"sampler_index": "Euler",
"script_name": "string",
"send_images": true,
"save_images": false,
"alwayson_scripts": {}
}
Currently the Implementation of SDL. uses only a Sub-Set of the most important Parameters.
You can add further Parameters using the SDL.Set Extra Parameter - Command.
Syntax
SDL.Set Extra Parameter|P1
Parameter Explanation
P1 - (optional) - Additional Extra-Parameters for the JSON. Just copy the Line from the JSON.
If you want to add multiple Extra Parameters separate them with a , (Comma).
Here we add 2 Extra Parameters.
SDL.Set Extra Parameter|"save_images": true,"n_iter": 2
Example
'***********************************
' IRS.-Sample
'***********************************
' We will now change only this line and add weight to the prompt
$$PRO=very small golden robot man on rainbow colored planet planet,galaxy,planets
$$NEG=ugly,comic,unrealistic,fat
SDL.Set Size free|512|512
FOR.$$LOO|140|150|2
SDL.SetSteps|$$LOO
SDL.Set Extra Parameter|"save_images": true,"n_iter": 2
FOR.$$LOP|0|21
SDL.Set_Sampler|$$LOP
SDL.Get Several|4|$$RET
DBP. Sampler=$$LOP ($$RET)
SDL.gtf|$$PRO|$$FIL|$$NEG|7
POP.$$PAT
POP.$$SUC
IVV.$$SUC=1
ANA.load|0|$$PAT
ANA.Resizeto|0|1|640|640
ANA.show|1
ANA.Save|1|$$PAT
ELS.
SDL.Get Several|6|$$RET
DBP.$$RETSetSteps|10
SDL.Show Error
MBT.No File generated.
EIF.
NEX.
NEX.
MBX.!
ENR.
Remarks
-
Limitations:
-
See also:
•
