MiniRobotLanguage (MRL)
SDO.Set Extra Parameter
Add extra Parameter to the JSON that is sent to the Local Stable Diffusion server
Generated using SDO. and the Script below.
Intention
The JSON that is sent to the Cloud Server using SDO is very different then what we use with SDL. on the Local Server.
Also the technical details are available Online, via the URL:https://platform.stability.ai/docs/api-reference#tag/v1generation
and https://platform.stability.ai/sandbox/text-to-image .
You can add Extra-Parameter, these will be saved in an internal Register (there is one for SDL. and another for SDO.)
this will insert the content of this register without any change into the JSON before its sent to the Server.
If the Variable is empty it will not be inserted.
There is no Syntax checking, the given Parameter will be inserted as it is.
If the resulting JSON is invalid, the call will not produce a picture and instead will result in an error-message.
Due to the refined Scripting language of the SPR, handling JSON is very easy. You can just copy the Line from the JSON below, enter your value and thats it.
If you want to add multiple Extra Parameters separate them with a , (Comma).
As currently the SPR supports all known parameters, there seems to be no need for this Command with SDO..
As AI develops, this command is for future Expansion. General use is like this:
SDO.Set Extra Parameter|"clip_guidance_preset": "FAST_BLUE","n_iter": 2
Below the complete List of parameters that can be used for the Cloud Server.
All of these Parameters, are already included in the
SDO.Generate Picture to File/Var Command, therefore you can just include them using the Standard Registers.
In case you include Text that needs to be escaped, its up to you to do so using the AIC.Escape - Command.
{
"cfg_scale": 7,
"clip_guidance_preset": "FAST_BLUE",
"height": 512,
"width": 512,
"sampler": "K_DPM_2_ANCESTRAL",
"samples": 1,
"steps": 75,
"text_prompts": [{}]
}
Syntax
SDO.Set Extra Parameter|P1
Parameter Explanation
P1 - (optional) - Additional Extra-Parameters for the JSON. Just copy the Line from the JSON.
If you want to add multiple Extra Parameters separate them with a , (Comma).
Here we add 2 Extra Parameters. One of them will create an error message from the Server using the Script below.
SDO.Set Extra Parameter|"clip_guidance_preset": "FAST_BLUE","n_iter": 2
Using Parameters that are not supported will bring up an Error Message, using the Script below.
Example
'***********************************
' SDO.-Sample
'***********************************
SDO.SetKey|File
SDO.SetSize|512|512|stable-diffusion-v1-5
' We will now change only this line and add weight to the prompt
$$PRO=golden robot man on rainbow colored planet planet,galaxy,planets
$$NEG=ugly,comic,unrealistic,fat
'SDL.Set Size free|512|512
FOR.$$LOO|140|150|2
SDO.SetSteps|$$LOO
' Currently this option will not change anything, we just use it to show usage
SDO.Set Extra Parameter|"n_iter": 2
FOR.$$LOP|0|21
SDO.Set_Sampler|$$LOP
SDL.Get Several|4|$$RET
DBP. Sampler=$$LOP ($$RET)
SDO.gtf|$$PRO|$$FIL|$$NEG|7
POP.$$PAT
POP.$$SUC
IVV.$$SUC=1
ANA.load|0|$$PAT
ANA.Resizeto|0|1|640|640
ANA.show|1
ANA.Save|1|$$PAT
ELS.
SDL.Get Several|6|$$RET
DBP.$$RETSetSteps|10
SDL.Show Error
MBT.No File generated.
EIF.
NEX.
NEX.
MBX.!
ENR.
Remarks
-
Limitations:
-
See also:
•
