MiniRobotLanguage (MRL)
PIS.SetButtonsHVSize Command
PIS.SetButtonsHSize Command
PIS.SetButtonsVSize Command
Set/Change Size of all Plugin-Buttons
Intention
The PIS.SetButtonsHVSize -Command will set or change the Size of the Buttons from the specified Buttonbar.
You can Re-Size the Buttons any time.
PIS.$$REA|SetButtonsHVSize|80|40
' Here we size the Buttons 80x40
PIS.$$REA|SetButtonsHVSize|160|30
' Here we size the Buttons 160x30
' If you specify a "0" as Size-Parameter, the value is not changed
PIS.$$REA|SetButtonsHVSize|80|0
Syntax
PIS.P1|SetButtonsHVSize|P2|P3
PIS.P1|sbhvs|P2|P3
PIS.P1|SetButtonsHSize|P2
PIS.P1|sbhs|P2
PIS.P1|SetButtonsVSize|P2
PIS.P1|sbvs|P2
Parameter Explanation
P1 - Variable which contains the PlugIn Index-No.
P2 - Value, first Size-Parameter in Pixel, if this value is "0" Size is not changed
only for the "sbhvs" - Command:
P3 - Value, second Size-Parameter in Pixel, if this value is "0" Size is not changed
All commands are specific for the type of PlugIn used.
Example
' This code is just a Syntax-Sample and will not run
PIS.$$REA|SetButtonsHVSize|80|40
PIS.$$REA|SetButtonsHVSize|270|90
PIS.$$REA|SetButtonsHSize|270
PIS.$$REA|SetButtonsVSize|90
Remarks
You can use up to 5 Plugins at the same time.
Just start them, each will get another Index.
To communicate with each PlugIn, you just give the PlugIn-Index to each command.
Button-Colors and transparency:
Please note that if you set Buttons transparent, that they can not have a background-color at the same time.
To set multiple Buttontext at once you can use:
PIS.$$PIN|sbt|all|Button %n
The "%n" is replaced with the number of that button.
The "all" and %n-scheme will also work with most other commands, where it makes sense.
Limitations:-
-
See also:
•
