MiniRobotLanguage (MRL)
ANA.GetBGColor
Returns the Color of the Background of an IR
Intention
This Command needs the ANA.AnalyzeColor Command to count colors in an IR before it will work. It may also need the "Force-Flag" (P2) to be set.
ANA.AnalyzeColor|0|1
' These are some further commands that can be used after the ANALYZE.
ANA.getcolorcount|0|$$CNT
ANA.getbgcolor|0|$$BGC
you can then work with the list entries.
This ccommand will return the color that is mostly used in the IR. It is assumed that the "Color of most of the Pixels" is the Background color.
IEF.$$PAT
ANA.Load|0|$$PAT
ANA.Show|0!
ELS.
MBX: FIle does not exist.
EIF.
ANA.AnalyzeColor|0|1
ANA.GetBgcolor|0|$$RES|$$ANZ
VTH.$$RES|$$HEX
MBX.$$HEX--$$ANZ
ENR.
Will bring up this Messagebox: that shows that the Color &HFEFEFE is most likely the Background Color. And this color is found 597379 times in the original picture.
With this picture:
Syntax
ANA.GetBGColor[|P1][|P2][|P3]
Parameter Explanation
P1 - Source Image-Register Number, if omitted 0 is used.
P2 - (Result) Color of Background, if omitted the result is placed on TOS.
P3 - (Result) Number of Pixels using the Color of Background (in P2), if omitted the result is placed on TOS.
The Command will not leave a 0/1 on the TOS. If the Operation fails, P2 may be "-1".
Example
'***********************************
' ANA.Fill-Sample
'***********************************
ANA.New|0|320|200
ANA.Fill|0|&HFFFFFF|1|&HFF0000
ANA.Show|0!
ENR.
' Below you can see the result of the Operation.
Remarks
-
Limitations:
-
See also:
