MiniRobotLanguage (MRL)
AIC.Get Rec State / AIC.grs
Returns recording state.
Intention
The AIC.Get Rec State command returns the current recording state of the system in the variable specified in P1.
The recording state is an internal register that can be read or altered, typically to stop the recording.
Here is a sample Script that shows how you can use the command together with Asynchronous Recording.
AIC.Set Key|file
' We create a Recording Button, to be able to stop the recording
AIC.Create Rec Button|0|0|1
VAF.$$FIL=?exeloc\Test.mp3
' We start the recording
AIC.Record Asynchron|$$FIL
DOL.
AIC.grs|$$RET
PRT.$$RET
OOP.($$RET>0)
ENR.
Syntax
AIC.Get Rec State|P1
AIC.Grs|P1
Parameter Explanation
P1: Optional. Variable to store the recording state. If omitted, the result is placed on the Top of Stack (TOS).
The following Rec-States will be returned:
0 - Buttons are in recording State (not Stopped, not Paused)
1 - Recording is PAUSED
2 - Recording is Stopped/Ended
3 - Stopped and Paused
Example
'***********************************
' IRS.-Sample
'***********************************
AIC.Set Key|file
' We create a Recording Button, to be able to stop the recording
AIC.Create Rec Button|1|0
VAF.$$FIL=?exeloc\Test.mp3
' We start the recording
AIC.Record Asynchron|$$FIL
DOL.
AIC.grs|$$RET
PRT.$$RET
OOP.($$RET>0)
ENR.
Remarks
-
Limitations:
-
See also:
•
